Pipe & Conduit

TGW1N

TBNMT

Material : Nylon 6 (Polyamide 6，PA6) + Tinned Copper Braiding
Temperature Range : -40℃~+105℃
Flexibility : Medium
Flammability Rating : UL94 V-0, UL94 V-2
UV Resistance : Yes
EMC Shielding：High
Environmental Protection :RoHs Compliance, Halogen Free
TGW1N

FOC

Material : Galvanized Steel (Oval)
Temperature Range : -50℃~+350℃
IP Rating : IP 40
Flexibility : Medium
RoHS Compliance : Yes
Certificate :cURus,E544375
TGW1N

PRT

Material : PA6
Temperature Range : -40℃~+105℃
Flexibility : Supreme (Swing test : 1 mllion times)
Flammability Rating : No
UV Resistance : No
Environmental Protection :RoHs Compliance, Halogen Free
TGW1N

RTT

Material : TPEE
Temperature Range : -30℃~+130℃
Flexibility : Supreme (Swing test : 2 mllion times)
Flammability Rating : No
UV Resistance : No
Environmental Protection :RoHs Compliance, Halogen Free
TGW1N

LTLFNCB
TGW1N

DNMT

Material : Nylon 6 (Polyamide 6 , PA6)

Temperature Range : -40℃~+105℃

 IP Rating : IP 40 (Fit with FN01~FN04 connector series: Nominal Conduit Size 16~54, exclyde 48) IP 40 (Fit with FN50, FN53 connector series: Nominal Conduit Size 48)

 Flexibility : High

 Flammability Rating : UL94 V-0, UL94 V-2 (Option: Non Flame Retardant)

 UV Resistance : Yes (Option: Non UV Resistance)

 Environmental Protection :RoHs Compliance, Halogen Free

Certificate :
TGW1N

RNT

Material : Nylon 6 (Polyamide 6 , PA6)
Temperature Range : -40℃~+105℃
IP Rating : IP 40 (Fit with FN01~FN04 connector series: Nominal Conduit Size 16~54, exclyde 48)
IP 40 (Fit with FN50, FN53 connector series: Nominal Conduit Size 48)
Flexibility : High
Flammability Rating : UL94 V-0, UL94 V-2 (Option: Non Flame Retardant)
UV Resistance : Yes (Option: Non UV Resistance)
Environmental Protection :RoHs Compliance, Halogen Free
TGW1N

LPH

Material : PVC + Polyester yarn + PVC
Temperature Range : -40℃~100℃
Color : Black
Working Pressure Rating：350psig (High Pressure), 1psig (Low Pressure)
Flexibility : High
Flammability Rating : FT4
UV & Ozone Resistance : Yes
RoHs Compliance：Yes
Certificate：cCSAus (High Pressure), CSAus (Low Pressure)
TGW1N

PNMT

Material : Thermoplastic Polyvinyl Chlpride (PVC)
Temperature Range : -18℃~+80℃
IP Rating : IP 66 (Fit with connector series: N161)
IP 68 (Fit with connector series: P50,P53,PP60 & PP63)
Color : Grey/Black
Flexibility : High
Fire Retardant : Self-extinguishing
UV Resistance : Yes
Certificate : Follow UL 1696 Standard, cULus,E544377
TGW1N

LTULTG

Material: Galvanized Steel  +  PVC jacket
Temperature Range: -50℃~+105℃ Dry， 75℃ Oil
IP Rating: IP 40(Fit with connector series: S52)IP 66(Fit with connector series: S50, S51& S53)
Jacket Color: Grey (Standard), other colors are avaiable by consult.
Flexibility: Medium
Fire Retardant: Self-extinguishing
UV Resistance: Yes
Certificate: CULus
